Gantry Fixed Beam Processing Center

Commodity name： Gantry Fixed Beam Processing Center

Category:

Gantry machining center

Download

Message

Description

Project	Unit	GM 3200	GM4000	GM4500	GM5500
Trip
X-axis travel	mm	4500	5500	6000	6500
Y-axis travel	mm	3200	4000	4500	5500
Z-axis travel	mm	1000/1200	1000/1250	1000/1250	1000/1250
Distance from spindle end face to worktable	mm	250-1200	350-1250	350-1250	350-1250
Distance between two pillars	mm	3200	4000	4500	5500
Workbench
Workbench size(length)	mm	4000	5000	6000	6500
Workbench size(wide)	mm	2800	3500	4000	5000
T-groove size ( Nointervawide)	mm	1428200	1236300	1336300	1736300

Project	Unit	GM 3200	GM 4000	GM 4500	GM 5500
Spindle
Spindle horse power (Consecutive /30 points)(ST)	kw	22/26/30/37	30/37	30/37	30/37
Range of spindle speed(ST)	rpm	4500/6000
Spindle form		Ful gear
Spindle taper hole specification		BBT 50			BT 50/DIN 50
Feed speed
X-axis move quickly	mm/min	20000/12000	20000/12000	20000/12000	20000/12000
Y-axis move quickly	mm/min	20000/12000	20000/12000	20000/12000	20000/12000
Z-axis move quicky	mm/min	12000	12000	12000	12000
Cutting Speed	mm/min	10000	10000	10000	10000
Positioning accuracy(Semi-closed loop)
X-axis travel	mm	0.015	0.015	0.02	0.02
Y-axis travel	mm	0.015
Z-axis travel	mm	0.01
Repeated positioning accuracy(Semi-closed loop)
X-axis	mm	0.008	0.008	0.01	0.01
Y-axis	mm	0.008
Z-axis	mm	0.006	0.006	0.008	0.008
